Apex Electronics APEX176 Hypercardioid Shotgun Microphone Microphone
This is theideal microphone for sound reinforcement applications where the microphoneneeds to have a tight pick-up pattern, but cannot be placed close to thesource. Shotgun microphones are most commonly used on sound-stages, for stageplays, for broadcast or for electronic newsgathering. This super-cardioidshotgun mic will run on either phantom or battery power.
Key Features
- ExtendedHypercardioid Pickup Pattern
- ExcellentOff-Axis Rejection
- 70HzLow-Frequency Roll Off Switch
- Operateswith Internal AA Battery or with Phantom Power
- Padded CarryBag, Deluxe Microphone Clip & Foam Windscreen Included
- IdealMicrophone for Remote Recording, Film and Broadcast Applications
TechnicalSpecifications
Element
BlackElectret Condenser
Frequency Response
50Hz – 20kHz
Sensitivity
-56dB (+/-3dB, 0dB = 1v/ubar@1kHz)
Impedance
300 OHM
S/N
72dB (1kHz @1Pa)
Max SPL
132dB (1kHz<1% THD)
Power Requirement
Internal AABattery or Phantom Power (9 to 48V)
Connection
XLR-M
Dimensions
14.5 x 0.75in / 368.3 x 19.5 mm
Weight
13.3 oz /392 g
