Lowell RY-4

Original price was: $186.78.Current price is: $128.03.

Sale!
SKU: RY-4- Categories: ,
Share


RY-4: Relay Module (classic)

General purpose relay module with 4 heavy duty double-pole double-throw (DPDT) relays.


FEATURES

  • Steel Chassis:  5 in. x 1.688 in. x 6.25 in.
  • 5A contact rating (24VDC/240VAC)
  • Four DPDT relays, each independent
  • Spike suppression and polarity protection diodes
  • Enclosed design protects relays and components
  • Relay can be field converted to AC operation by installing an electrolytic capacitor
  • Holes for screw-mount installation

COMPLIANCE & CERTIFICATION

  • Made in U.S.A. with global components

A&E SPECIFICATIONS

  • The relay module shall be Lowell Model No.RY-4 to provide four heavy duty DPDT relays. The relay shall have a contact rating of 5 Amps, 24VDC/240VAC. The relay shall be have spike suppression capability, polarity protection diodes and three-sided barrier strip terminals with wire clamps. The module shall be enclosed in a steel chassis measuring 5 in. x 1.69 in. x 6.25 in. It shall have a black semi-gloss finish and holes for wall or shelf mount.
