Lowell TLM-10070A

Original price was: $119.10.Current price is: $62.00.

Sale!
SKU: TLM-10070A Categories: ,
Share


Transformer TLM-10070A (100W)


High performance line-matching 100W transformer.


FEATURES

  • Primary Voltage:  70V
  • Power Rating:   100W
  • Primary Taps:  16, 32, 64, 100W
  • Secondary Impedance:  8, 4 ohms
  • Frequency Response:  50Hz–15kHz (±1dB)
  • Lead Length:  18 in.
  • Leads:  Color-coded
  • Unit Size:  3.75 in. x 3.125 in. x 2.937 in.

A&E SPECIFICATIONS

  • The line matching 100W transformer shall be Lowell Model TLM-10070A. Primary voltage shall be 70V with a power rating of 100 watts. Primary taps shall be available at 100/64/32/16 watts. Secondary impedance taps shall be available at 8 ohms and 4 ohms. All taps shall have clearly marked color-coded leads. Frequency response of the transformer shall be 50Hz–15kHz (±1dB) with insertion loss not to exceed 0.6 dB.
