Features
Core Technology
- Bus-powered USB 2.0/iPad® audio interface
- 24-bit resolution; 44.1, 48, 88.2, and 96 kHz sampling rate
Inputs and Outputs
- 2 microphone inputs with low-noise, high-headroom, Class A mic preamplifiers and +48V phantom power
- 2 switchable line/instrument inputs
- 2 balanced ¼-inch TRS main line-level outputs
- 1×1 MIDI In/Out
- Stereo headphone output with independent level control
Controls
- Zero-latency monitoring via internal analog mixer (variable mix via Mix knob)
- Large main volume knob
- Signal present and clipping LEDs
Integrated Software
- Studio One® Artist DAW software (macOS®/Windows®) and 6+ GB of third-party resources
- Transfer files wirelessly from Capture for iPad to Studio One
- Compatible with almost all recording software for Mac, Windows, and iPad
- Studio Magic Software Suite included
Construction and Security
- Kensington lock hole
- Metal chassis
|
Computer system requirements:
Below are the minimum computer-system requirements for the AudioBox iTwo:
macOS®
- macOS® 10.13 or higher (64-bit only)
- Intel® Core™ i3 or better (M1 native compatible)
- Minimum 4 GB RAM / Recommended 8 GB or more
Windows®
- Windows® 10 (64-bit only)
- Intel® Core™ i3/AMD A10 processor or better
- Minimum 4 GB RAM / Recommended 8 GB or more
Mac and Windows Systems
- USB 2.0 port
- Internet connection
- Internal or external 7200 RPM storage drive highly recommended
- 30 GB hard disk space
- Monitor with 1366×768 resolution
Apple iPad
- iPad® Pro, iPad Air, iPad mini with Retina display, iPad (4th generation)
- iOS® 9.0.3 or higher
The minimum system requirements may differ for DAWs other than Studio One. Please check the requirements for your DAW of choice with its manufacturer.
Note that the speed of your processor, amount of RAM and size and speed of your hard drive will greatly affect the overall performance of your recording system. Also, a more powerful system (faster processor with more RAM) will allow for lower latency (signal delay) than you might experience while monitoring audio or MIDI signals. Monitor resolution for both PC and Macintosh should be no lower than 1024×768 pixels.
VST is a registered trademark of Steinberg Media Technologies GmbH
ASIO is a trademark and software of Steinberg Media Technologies GmbH
Technical Specifications
Mi crophone Preamp
|
|
| Type |
XLR female, balanced |
| Frequency Response (±3.0 dB) |
20 Hz to 20 kHz |
| Input Impedance (Balanced) |
1,200? |
| THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) |
<0.008% |
| S/N Ratio (Unity Gain, Ref. = +4 dBu, 20 Hz to 22 kHz) |
> 95 dB |
| Common Mode Rejection Ratio (1 kHz, 52 dB Gain) |
— |
| Gain Control Range (± 1 dB) |
0 dB to 52 dB |
| Max Input Level (Unity Gain, 1 kHz @ 0.5% THD+N) |
+10 dBu |
| Phantom Power (±2 VDC) |
+48 VDC |
Line Input
|
|
| Type |
¼” TRS female, balanced |
| Input Impedance |
10 k? |
Instrument Input
|
|
| Type |
¼” TS female, unbalanced |
| Input Impedance |
1 M? |
Line Outputs
|
|
| Type |
¼” TRS female, balanced |
| Output Impedance |
51? |
Headphone Output
Type ¼” TRS active stereo
Maximum Output 60 mW/ch. @ 60? Load
Frequency Response (±1.0 dB) 20 Hz – 30 kHz
MIDI I/O
Type Dual 5-pin female DIN
Digital Audio
ADC Dynamic Range (A-wtd, 48 kHz Sample Rate) 105 dB
DAC Dynamic Range (A-wtd, 48 kHz Sample Rate) 105 dB
Bit Depth 24
Reference Level for 0 dBFS +10 dBu
Internal Sample Frequency Selections (kHz) 44.1, 48, 88.2, 96
Power USB bus-powered
Physical
Height 1.71” (43.5 mm)
Depth 5.31″ (135 mm)
Width 7.56” (192 mm)
Weight 1.35 lbs (0.62 kg)
|
